20.2 MAP® 工業控制與軌道通訊適配電纜組裝 M8/M12 Plug RJ-45 Connector

整合軌道車輛車間通信功能與工具機訊號介面,我們提出了其適配電纜(低煙無鹵)與工業M8/M12接頭的方案。迅速整合設備端的介面切換,高相容的特性,廣泛應用於軌道車輛、航太控制、工業設備等產業。線纜搭載乙太網路電纜超六類以上等級(CAT6A. S/FTP),達到訊號傳輸頻寬500MHz與速度達10G bmps的水準。

Integrating the rail vehicle communication function and the machine tool signal interface, we propose a solution for its adapter cable (low smoke free halogen) and industrial M8/M12 connector. Quickly integrate interface switching on the device side, highly compatible features, widely used in railway, aerospace control, industrial equipment and other industries. This cable is equipped with an Ethernet cable of categories 6A. (CAT6A. S/FTP), achieving a signal transmission bandwidth of 500MHz and a speed of 10G bmps..

Part Number.	Connector	Waterproof Rating	Cable	Length
70141500A	M8 to RJ-45	IP67 and UL94V-0	CAT.6A F/FTP	3 Meter
701415001	M8 to RJ-45	IP67 and UL94V-0	CAT.6A F/FTP	5 Meter
701415003	M8 to RJ-45	IP67 and UL94V-0	CAT.6A F/FTP	10 Meter
70141500G	M8 to RJ-45	IP68 and UL94V-0	CAT.6A S/FTP	15 Meter
701415005	M8 to RJ-45	IP68 and UL94V-0	CAT.6A S/FTP	20 Meter
70141500S	M8 to RJ-45	IP68 and UL94V-0	CAT.6A SSTP	30 Meter

Part Number.	Connector	Waterproof Rating	Cable	Length
70141500D	M12 to RJ-45	IP67 and UL94V-0	CAT.7 F/FTP	3 Meter
70141500K	M12 to RJ-45	IP67 and UL94V-0	CAT.7 F/FTP	5 Meter
701415002	M12 to RJ-45	IP67 and UL94V-0	CAT.7 F/FTP	10 Meter
701415004	M12 to RJ-45	IP68 and UL94V-0	CAT.7 S/FTP	15 Meter
701415006	M12 to RJ-45	IP68 and UL94V-0	CAT.7 S/FTP	20 Meter
70141500X	M12 to RJ-45	IP68 and UL94V-0	CAT.7 SSTP	30 Meter
