COMBINATION U.S. CUSTOMARY SYSTEM AND METRIC SYSTEM MULTIPLIER DRIVEN INDICATORS

Input Drive Female Square, inches

Output Drive Male Square, inches

Memory Needle Models

Light Signal Models

Range lb.ft.

Increments lb.ft.

Range Kg·m

Increments Kg·m

3/4

3/4

DX4F600CFMM

DX4F600CFML

600

20

80

2

1

1

DX5F1000CFMM

DX5F1000CFML

1000

20

136

2

1

DX5F1500CFMM

DX5F1500CFML

1500

25

200

5

1

DX5F2000CFMM

DX5F2000CFML

2000

50

280

5

1 1/2

1 1/2

DX6F2000CFMM

DX6F2000CFML

2000

50

280

5

1 1/2

DX6F3000CFMM

DX6F3000CFML

3000

100

400

5

1 1/2

DX6F4000CFMM

DX6F4000CFML

4000

50

550

10

2 1/2

2 1/2

DX7F10000CFMM

DX7F10000CFML

10000

100

1400

20

U.S. CUSTOMARY SYSTEM MULTIPLIER DRIVEN INDICATORS

Input Drive Female Square, inches

Output Drive Male Square, inches

Memory Needle Models

Light Signal Models

Range lb.ft.

Range lb.ft.

Optional “T” Bars/ Length

Optional Extension Handles/ Length

3/4

3/4

DX4F600FM

DX4F600FL

600

10

79TQP — 45”

-

1

1

DX5F1000FM

DX5F1000FL

1000

10

81TQP — 66”

-

1

DX5F1500FM

DX5F1500FL

1500

25

82TQP — 45”

85TQP — 31”

1

DX5F2000FM

DX5F2000FL

2000

25

82TQP — 18”

85TQP — 31”

1 1/2

1 1/2

DX6F2000FM

DX6F2000FL

2000

25

82TQP — 18”

85TQP — 31”

1 1/2

DX6F3000FM

DX6F3000FL

3000

50

83TQP — 18”

87TQP — 66”

1 1/2

DX6F4000FM

DX6F3000FL

4000

50

83TQP — 18”

87TQP — 66”

2 1/2

2 1/2

DX7F10000FM

DX7F10000FL

10000

100

-

-
