【AEG ID】Antenna AAN X1F flex. 2.5m cable 現貨 (編號:1002367)

Antenna AAN X1

The antenna ANN X1 is a passive unit designed for the ARE i2 reader. Because of its small dimensions ( 30x40 mm ), it is well suited as well for both, static as well as dynamic applications. It is available as air core coil or ferrite coil respectively.

• ELECTRICAL CHARACTERISTICS
• reading system ARE i2 LF
• operational frequency 125 kHz, 134.2 kHz
• ENVIRONMENT
• storage temperature -20°C up to +70°C (+140°C opt. only antenna)
• operating temperature -20°C up to +70°C (+140°C opt. only antenna)
• housing protection IP 65
• schock & vibration IEC 68-2-6 / 29
• DIMENSIONS
• Weight Ca. 50 g
• Length 46 mm
• Width 30 mm
• Height 10 mm
• Material Plastic
• ADDITIONAL INFORMATION
• cable length between antenna electronics and reader: max. 10 m flexible | rigid high-temperatur cable opt.
