📌Features
Support ISO14443, MIFARE Classic® 1K, MIFARE Classic® 4K and MIFARE Ultralight®.
Operating Frequency:13.56MHZ
Card Type:Philips Mifare 1 S50, serial numbers from MIFARE Plus®, MIFARE® DESFire® and any transponder compatible with the ISO14443A standard
Reading Range:3cm~5cm
Communication Interface:RS232 9600,n,8,1
Output Interface: Wiegand 26、34、etc....or ISO ABA II
Can connect extra LED
Antenna is included
📌Specifications
| Power |
DC5V 200mA |
| Operating Temperature |
-20℃~70℃ |
| Relative Humidity |
20% ~90% |
| Dimension |
72x40x5mm (with antenna) |
