Maximum input level
Sample rate
48 kHz, 96 kHz
Dynamic range
>107 dB unweighted (20 Hz - 20 kHz)
Mic/Line (Unity Gain)
+21 dBu
Mic/Line (-2.5 dB Gain)
+24 dBu
CMRR @ 1 kHz
Mic Input (Unity Gain)
>60 dB
Mic Input (40 dB Gain)
>90 dB
Mic EIN (40 dB Gain)
-126 dBu
Maximum Output Level
+21 dBu into 600 O
Output Noise (Unity Gain)
-86 dBu
Frequency Response
±0.5 dB (20 Hz - 20 kHz, relative to 1 kHz)
THD+N (Unity Gain)
<0.01%
Crosstalk @ 1 kHz
<-90 dB
System Inputs and Outputs
Analogue Inputs
16
Type
Mic/Line Level
Connector
3-pin XLR Balanced
Input Impedance
10k O
A/D Conversion
24 bit, 96 kHz with 128 times oversampling
Phantom Power
+48V, individually switchable per channel
Analogue Outputs
8
Type
Line Level
Connector
3-pin XLR Balanced
Output Impedance
50 O
D/A Conversion
24 bit, 96 kHz with 128 times oversampling
Network Connections
2
Connector
Neutrik etherCON with status LEDs
Redundancy
Dual cable redundancy
Network Interface
Conforms to AES50-2011
Ethernet Control Port
1
Connector
Neutrik etherCON with status LEDs
Power
1
Connector
IEC mains inlet
Mains Input Voltage
100 to 240 VAC, 50-60 Hz
Power Consumption
<150 W
